COEUS-UEX Ultra Low Temperature Data Logger

COEUS-UEX Ultra Low Temperature Data Logger

Temperature range: 90℃~+200℃/-130℉~392℉ (External probe)，0% ~ 99%(Internal probe)

Temperature Accuracy: ±0.5℃/0.9℉(-90℃～+70℃/-130℉ ~ 158℉) ±1℃/34℉ (Others)，±3% RH

Run Days: Max. 300 days

The COEUS-UEX Ultra Low Temperature Data Logger is a multipurpose, rechargeable, configurable dry ice ultra low temperature data logger with large temperature and humidity display.

Introduction

The COEUS-UEX Ultra Low Temperature Data Logger is a versatile wide range temperature and humidity controller with a high resolution temperature range from -90°C to +200°C, providing up to 35,000 readings with real-time temperature data and time. The built-in PDF/CSV file generation function allows this thermometer hygrometer to directly generate irreversible data reports in PDF/CSV format by connecting the logger with a PC without any software.

Features

1. Intuitive large LCD screen, real-time view of current temperature and humidity, maximum/minimum temperature and humidity, date and time, and battery power.

2. High-precision and large data capacity, the 2-meter external probe can measure the temperature as low as -90°C with high precision. Up to 35,000 memory capacity.

3. Sound and light alarm, temperature and humidity meter can be set to 3 groups of high and low temperature alarm. When the temperature exceeds the preset value, there will be a buzzer alarm and the red light will flash as a warning.

4. You can choose built-in or external sensor measurement when you use it for the first time according to your needs, or you can switch between built-in and external sensors by short pressing the button during use.

5. The battery is rechargeable for long working hours, with a rechargeable lithium battery that works up to 300 days.

6. Interim reports are automatically generated when the cryogenic sensor is connected to a computer’s USB port.

Specification

Model	COEUS-UEX	Type	Reusable
Memory Capacity	Max. 35000 readings	Shelf Life	2 years
Sensor	PT100 sensor	Display	LCD screen
Temperature Range	-90℃~+200℃/-130℉~392℉ (External probe)	Temperature Accuracy	±0.5℃/0.9℉(-90℃～+70℃/-130℉ ~ 158℉) ±1℃/34℉ (Others)
Humidity Range	0% ~ 99%(Internal probe)	Humidity Accuracy	±3% RH
Start Mode	Configurable	Logging Interval	1 minute-24 hours
Alarm Points	Max. 6 points	Mark Point	Max. 9 points
Alarm Type	LCD indication, audible and visual	Alarm Sound Level	>70dB at 3 m
Connection	Type C, USB, NFC (optional)	Battery	18650,4.2V,2600mAh
Report Format	PDF/CSV/PDF&CSV	Compatible OS	WIN7/8/10
Certifications	CE, RoHS	Dimensions	107mm78mm32mm
Weight	About 160g	Run Days	Max. 300 days
LCD Screen Display	Current temperature and humidity values, Max. and Min. temperature and humidity values, Mark event, date and time, Remaining power

Applications

COEUS-UEX Ultra Low Temperature Data Logger can be used in medical industry, food industry, production workshop, agricultural research, biological laboratory and other fields. It can also be used in museums and archives, these also need to keep valuables in a certain temperature and humidity environment. So this temperature sensor is also needed to record the real-time temperature to ensure its integrity.
